Ford Super Duty (11-16) Fog Pocket Kit SAE Amber Baja Designs

Manufacturer: Baja Designs

SKU: 447731-FGXX

Manufacturer part number: 447731

Be the first to review this product

$519.95

Qty:

+ -

Vehicle Fitments

Make	Model	Submdel	From	To
Ford	F-350 Super Duty	King Ranch	2011	2016
Ford	F-250 Super Duty	King Ranch	2011	2016
Ford	F-250 Super Duty	Lariat	2011	2016
Ford	F-350 Super Duty	Lariat	2011	2016
Ford	F-250 Super Duty	XL	2011	2016
Ford	F-350 Super Duty	XL	2011	2016
Ford	F-250 Super Duty	XLT	2011	2016
Ford	F-350 Super Duty	XLT	2011	2016
Ford	F-250 Super Duty	Platinum	2013	2016
Ford	F-350 Super Duty	Platinum	2013	2016

Overview
Specifications
Reviews
Contact Us

The Ford Super Duty (11-16) Fog Pocket Kit allows you to mount 2 SAE Squadron auxiliary lights in the factory location. This Plug and Play kit includes two Squadron Pro Wide Cornering lights, two vehicle specific mounting brackets and a wiring adapter, allowing you to use your factory switch and mounting hardware.

Includes:

x2 Ford Super Duty (11-16) Fog Pocket Brackets
x2 Wiring Adapters
x2 Squadron SAE Amber with Vehicle Specific Bezels

Baja Designs Features:

Satisfaction Guarantee - 30 Day Money Back Guarantee
Limited Lifetime Warranty - Complete Purchase Protection
uService- Replaceable Lenses And Optics
ClearView - All The Light, Right Where You Need It.
MoistureBlock - Waterproof, Rain Proof, Submersible
CopperDrive - Only LED Driven At 100 percent
5000K Daylight - Less Driver Fatigue, Natural Color

Specifications (Per Light):

Lumens: 2,480 Utilizing 4 Cree LEDs
Compliance Standard: SAE Standard J583
Wattage/Amps: 22W / 1.6A
Dimensions: 3.07 inch x 2.77 inch x 3.07 inch
Weight: 12 ounces
LED Life Expectancy: 49,930 Hours
Front Lens: Hard Coated Polycarbonate
Housing: Hard Anodized & Powder Coated Cast Aluminum
Bezel: Billet Machined Aluminum
Hardware and Bracket Material: Stainless Steel
Exceeds MIL-STD810G (Mil-Spec Testing)
Built-In Overvoltage Protection
IP69K (Waterproof, Submersible to 9ft)
IK10 Compliant (Mechanical Impact Testing)

Patterns:

Driving/Combo: Maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Driving (42 degree) and spot (9 degree) optics to provide you with a smooth blend of light for both near field applications and distance (Lighting Zone 3)

Wide Cornering: BD was the first to develop a pattern specifically for cornering, dust and/or fog conditions. The Wide Driving pattern offers a 42 degree flattened horizontal beam for the ultimate in comfort lighting. (Lighting Zones 1 & 2)

Spot: A longer and narrower 9 degree beam focus for illumination further down the trail or road. The Spot pattern is designed to be used in conjunction with additional Wide Driving and/or Driving/Combo beam lights. (Lighting Zone 4 & 5)

Products specifications

Country of Origin	USA
Sold As	Kit
UPC	810031740895
Availability	Available
Universal	No
Bracket Material	Stainless Steel
Brackets Included	Yes
Housing Type	Aircraft Grade Aluminum w/Mil-Spec Hard Anodize
IK10 Compliant	IK10 Compliant (Mechanical Impact Testing)
Lens Color	Clear
Lens Material	Hard Coated Polycarbonate
Life Span Expectancy	49,930 Hours
Waterproof Rating	IP69K (Waterproof up to 9ft Pressure Washable)
Finish	Powdercoat
Color	Clear
Proposition 65 Warnings	CALIFORNIA WARNING: Cancer and Reproductive Harm -www.P65Warnings.ca.gov
