XL Pro LED Husqvarna Kit 20-Pres Baja Designs

Manufacturer: Baja Designs

SKU: 507020-FGXX

Manufacturer part number: 507020

Be the first to review this product

$393.95

Qty:

+ -

Overview
Specifications
Reviews
Contact Us

The Husqvarna XL Pro has been designed for the enthusiast and the racer looking to extend their ride time and increase daytime awareness. This kit features an extreme amount of beam pattern adjustability.

Our High Speed Spot Reflectors provide record setting distance, wide peripheral spread. A seamlessly smooth beam pattern, and offers a 25 percent dimming feature. An industry first 30 Day Satisfaction Guarantee and Limited Lifetime Warranty is included for the ultimate in purchase protection.

If you have a factory dual sport bike and would like to maintain the High/Low function of the bike please look at the part XL, Husqvarna/K Hi-Low Harness
Note: Electric start bikes that require a stator modification or rewind will have to the purchase a switch and wiring harness kit

(Does Fit 701 Model)

For Electric-Start Bikes: Some electric-start bikes require the stator to be modified or rewound as well as the addition of a new rectifier/regulator to run LED lights. If your bike requires a new rectifier/regulator please order part (12-2004) (please provide year/make/model of bike).

Detailed stator modification instructions and hardware is included for all bikes that require a stator modification to run LED lights. If your bike requires the stator to be rewound, please call Baja Designs for an order confirmation number to have this service performed.

Baja Designs Features:

Satisfactions Guarantee - 30 Day Money Back Guarantee
Limited Lifetime Warranty - Complete Purchase Protection
uService - Replaceable Lenses And Optics
ClearView - All The Light, Right Where You Need It.
MoistureBlock - Waterproof, Rain Proof, Submersible
CopperDrive - Only LED Driven At 100 percent
5000K Daylight - Less Driver Fatigue, Natural Color

Specifications:

Lumens: 4,900 Utilizing 4 Cree XP-L LEDs
Wattage/Amps: 40W / 2.90A
Weight: 1.85 lbs
LED Life Expectancy: 49,930 Hours
Front Lens: Hardcoated Polycarbonate
Housing: Hard Anodized Aluminum
Bezel: Billet Powdercoated Aluminum
Hardware and Bracket Material: Stainless Steel
Exceeds MIL-STD810G (Mil-Spec Testing)
Built-In Overvoltage Protection
IP69K (Waterproof up to 9ft and Pressure Washable)
IK10 Compliant (Mechanical Impact Testing)

Includes:

XL Pro Husqvarna LED Light Kit (20 - On)

Patterns:

Driving/Combo: Maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Wide Driving (42 degree) and the spot (6 degree) optics to provide you with a smooth blend of light for both near field applications and distance (Lighting Zone 3)

Products specifications

Country of Origin	USA
Sold As	Kit
UPC	810031740406
Availability	Available
Universal	No
Bracket Material	Stainless Steel
Brackets Included	Yes
Housing Type	Hard Anodized Aluminum
Lens Color	Clear
Lens Material	Hard Coated Polycarbonate
Life Span Expectancy	49,930 Hours
Light Pattern	Driving/Combo
Mfg Label	Headlight Kit
Waterproof Rating	IP69K Waterproof
Wattage/AMP	40W / 3.33A
Youtube Video	https://youtu.be/4JuV5ppJ2Mo
Series	XL Pro Series
Lumens	4,900
Color	Black
Proposition 65 Warnings	CALIFORNIA WARNING: Cancer and Reproductive Harm -www.P65Warnings.ca.gov
